N2P10L Normal Beam Probe

Pulse Echo Probe for Contact Technique

Transducer dimensions:    Ø 10 mm
frequency:                          2 MHz
dimension:                         42 x 20 x 25 mm
Near field length:               17 mm
connection:                        Lemo 00

139,00 €
excl. 19% VAT
  • Delivery time: 10 - 11 Workdays (Other countries)
Description
Pulse Echo Probe for Contact Technique:

Technical Data Reference Dimensions
Echo pulse duration 1408.00 ns
Centre frequency 2.08 MHz
Relative bandwidth -6 dB* 51.14 %
Relative pulse-echo sensitivity     -34.25 dB
Transducer dimensions Ø 10 mm
Near field length 8 mm
Dimension high 42 mm
Dimension Ø top 20 mm
Dimension Ø down 25 mm
Electrical connection LEMO 00
Housing material Stainless steel, Plastics
Weight 50 g
